The slide outlines the Flask request-response workflow: a client sends an HTTP request, which Flask routes by matching URL and method, executes the target function with extracted parameters, and runs business logic on a hardcoded users list. A JSON response with appropriate status codes (e.g., 200, 404) is then generated and returned.
Request & Response Flow
{ "headers": [ "Step", "Action", "Details" ], "rows": [ [ "1. Client HTTP request", "Client sends HTTP request", "Includes URL, method (GET/POST/etc.), headers, and optional body data" ], [ "2. Flask matches URL+method", "Flask router processes request", "Matches URL path and HTTP method to registered route decorator" ], [ "3. Route executes", "Target route function is called", "Parameters (e.g., <int:user_id>) are extracted and passed" ], [ "4. Business logic", "Core application logic runs", "Performs CRUD operations on hardcoded users list" ], [ "5. JSON response + status codes", "Response generated and sent", "jsonify() converts data to JSON; appropriate HTTP status (200, 201, 404, etc.) returned" ] ] }
Source: Flask CRUD Operations Using Hardcoded User Data (No Database)
Speaker Notes
Correct codes ensure professional APIs.
Using correct status codes makes APIs professional and standard-compliant.
